GC Standards, Reference Materials and Consumables
All standards, reference materials and consumable products we offer help you achieve the very best performance possible. Our calibration standards are produced in house by specially trained personnel and tested to meet or exceed test method criteria.
Are you unsure which standard or consumable product is best for your application or don’t happen to see the one you are looking for? Just give us call. We would be pleased to help.
Contact Us Today
| Test Method Reference | Product Description | Part Number |
|---|---|---|
| High Performance GC Columns | ||
| ASTM D2887 | Wide bore capillary column for ASTM D2887 / Procedure A; 10 M X 0.53 mm X 2.65 um PDMS | SD-002-2 |
| ASTM D2887 (‘Accelerated”) | Wide bore capillary column; 5 M X 0.53 mm X 3.0 um PDMS | SD-002-5M |
| ASTM D2887, D7213 (‘Extended’) | Wide bore capillary column; 10 M X 0.53 mm X 0.9 um PDMS | SD-002-EX2 |
| ASTM D2887 | Wide bore capillary column for D2887; Procedure B; 5 M X 0.53 mm X 2.65 um PDMS | SD-002-HTC5 |
| ASTM D6352, D7169, D7213, D7500 | Wide bore capillary column (metal clad) for high temperature simulated distillation; 5 M X 0.53 mm X 0.1 um PDMS | SD-002-HTE2 |
| ASTM D7096 | Wide bore (530u) column; 30 M X 0.53 mm X 5.0um PDMS | SD-003 |
| ASTM D5134, D6729, D6733, D7900 | Ultra-high resolution capillary column for DHA/PIANO analysis; 100 M X 0.25 mm X 0.5 PDMS | SD-009 |
| ASTM D5134, D6729, D6730, D6733, D7900 | Ultra-high resolution capillary column (100 M) and pre-column for DHA/PIANO analysis; 100 M X 0.25 mm X 0.5 um PDMS + 2 M X 0.32 mm 5% phenyl/95% PDMS pre-column | SD-009-6730 |
| ASTM D1945, D1946, D7833, UOP 539 | Refinery Gas Analyzer (7) Column Kit – For Separation Systems RGA system | SS-115-900-300-00 |
| Calibration Standards and Reference Materials | ||
| ASTM D2887 | Reference Gas Oil; Lot #1 Batch 2; 25 mL | SD-016-02 |
| ASTM D2887 | Reference Gas Oil; Lot #1 Batch 2; 5 mL | SD-016-05 |
| ASTM D2887 | Retention time & response factor (gravimetric) standard ; 0.01 – 0.1% C5-C44 in carbon disulfide; 6 X 1 mL | SD-SS3E-02 |
| ASTM D2887 | Retention time & response factor (gravimetric) standard ; 0.01 – 0.1% C5-C44; dry powdered form contains no carbon disulfide; must be reconstituted in carbon disulfide prior to use according to included instructions to produce ~7 mL | SD-SS3E-02-NS |
| ASTM D2887 | Retention time standard; 0.02-0.2% C5-C44 including trace n-C3, n-C4, and i-C4 in carbon disulfide; 6 X 1 mL | SD-SS3E-02-2X-WG |
| ASTM D7213 | Retention time standard; 0.02 – 0.1% C5-C72 with C12 and C40 markers in carbon disulfide; Polywax 500; 6 X 1 mL | SD-SS3E-03 |
| ASTM D7213 | Retention time standard; C5-C72 with C12 and C40 markers; Polywax 500; dry powdered form; contains no carbon disulfide; must be reconstituted in carbon disulfide prior to use according to included instructions to produce ~7 mL | SD-SS3E-03-NS |
| ASTM D4815 | ASTM D4815 calibration standard; 5 levels of 4 oxygenates (MeOH, EtOH, MTBE and TAME) plus internal standard (1, 2 dimethoxyethane) in isooctane/p-xylenematrix; 5 X 1 mL | SS-ASTM-D4815-04 |
| ASTM D4815 | Calibration standard with 5 levels of 12 oxygenates (contains most of the oxygenates specified by the method, but can be customized) and internal standard (1,2-dimethoxyethane) in isooctane/p-xylene; 5 X 1 mL | SS-ASTM-D4815-CSTM |
| ASTM D4815 | Retention time mixture containing 13 oxygenates, benzene, and internal standard (1,2-dimethoxyethane); 6 X 1 mL | SS-ASTM-D4815-RT |
| ASTM D4815 | Valve timing mixture containing hexane, MCP (methylcyclopentane), DIPE (diisopropyl ether), MTBE, and ETBE; 6 X 1 mL | SS-ASTM-D4815-VT |
| ASTM D5134, D6729, D6730, D6733, D7900 | DHA gravimetric standard for use with Separation Systems DHA GC-FID/MS system; 1 mL | SD-028-MS |
| ASTM D5134, D6729, D6730, D6733, D7900 | Standard to set pre-fractionation valve timing on Separation Systems DHA system | SD-040 |
| ASTM D5134, D6729, D6730, D6733, D7900 | DHA/PIONA standard/reference material (naphtha blend with >400 components individually identified components using MS); 6 X 1 mL | SD-053-006 |
| ASTM D5134, D6729, D6730, D6733, D7900 | DHA/PIONA standard/reference material (naphtha blend with >400 components MS individually identified components using MS); 1 mL (This part number is included with the purchase of Hydrocarbon Expert software) | SD-053-001 |
| ASTM D5134, D6729, D6730, D6733, D7900 | DHA/PIONA reference material (naphtha blend) with oxygenates; 6 X 1 mL | SD-053-010 |
| ASTM D5134, D6729, D6730, D6733, D7900 | DHA/PIONA reference material (naphtha blend) with oxygenates; 1 mL | SD-053-011 |
| ASTM D5134, D6729, D6730, D6733, D7900 | DHA/PIONA reference material (naphtha blend) with oxygenates; 6 X 1 mL | SD-053-016 |
| ASTM D5134, D6729, D6730, D6733, D7900 | DHA/PIONA reference material (naphtha blend with gases); 1 mL | SD-053-WG-001 |
| ASTM D5134, D6729, D6730, D6733, D7900 | DHA/PIONA reference material (naphtha blend with gases); 6 X 1 mL | SD-053-WG-006 |
| ASTM D5134, D6729, D6730, D6733, D7900 | DHA/PIONA 28 component gravimetric standard for DHA; 1 mL (Note: If using with ASTM D7900 backflush valve must be turned off. 1 mL volume is insufficient to add an internal standard.) | SD-053-030 |
| ASTM D5134, D6729, D6730, D6733, D7900 | DHA/PIONA 28 component gravimetric standard for DHA; 6 X 1 mL
(Note: If using with ASTM D7900 backflush valve must be turned off. 1 mL volume is insufficient to add an internal standard.) |
SD-053-036 |
| ASTM D5134, D6729, D6730, D6733, D7900 | DHA/PIONA reference material (light naphtha); 1 mL | SD-053-040 |
| ASTM D5134, D6729, D6730, D6733, D7900 | DHA/PIONA reference material (heavy naphtha); 1 mL | SD-053-050 |
| ASTM D5134, D6729, D6730, D6733, D7900 | DHA/PIONA reference material (heavy naphtha II); 1 mL | SD-053-051 |
| ASTM D5134, D6729, D6730, D6733, D7900 | DHA/PIONA reference material (alkylate); 1 mL | SD-053-060 |
| ASTM D5134, D6729, D6730, D6733, D7900 | DHA/PIONA reference material (reformate); 1 mL | SD-053-070 |
| ASTM D5134, D6729, D6730, D6733, D7900 | DHA/PIONA reference material (reformate product);1 mL | SD-053-080 |
| ASTM D5134, D6729, D6730, D6733, D7900 | DHA/PIONA reference material (FCC gasoline – treated); 1 mL | SD-053-090 |
| ASTM D5134, D6729, D6730, D6733, D7900 | DHA/PIONA reference material (FCC gasoline – untreated); 1 mL | SD-053-100 |
| ASTM D5134, D6729, D6730, D6733, D7900 | DHA/PIONA reference material kit consisting of light naphtha, heavy naphtha, heavy naphtha II, akylate, reformate feed, reformate product, gasoline (untreated and treated) matrices; 8 X 1 mL | SD-053-KIT |
| ASTM D5307 | Internal standard for D5307; C14-C17; 25 mL | SD-005 |
| ASTM D5501 | Calibration standard for ASTM D5501; 6 X 1 mL | SD-ASTM-D5501-01 |
| ASTM D5501 | Daily check standard for ASTM D5501; 6 X 1ml | SD-ASTM-D5501-03 |
| ASTM D5501 | Standards kit for D5501; SD-ASTM-D5501-01 + SD-ASTM-D5501-03 | SD-ASTM-D5501-05 |
| ASTM D6352 | Retention time standard for high temp simulated distillation; 0.005% – 0.04% C10 – C100 with C40 marker; Polywax 655; 6 X 1 mL | SD-SS3E-06 |
| ASTM D7096 | Retention time standard; no oxygenate(s) added; 6 X 1 mL | SD-008 |
| ASTM D7096 | Retention time and response factor standard with ethanol; 6 X 1 mL | SD-060 |
| ASTM D7096 | Retention time and response factor standard; no oxygenate(s) added; 6 X 1 mL | SD-060-05 |
| ASTM D7096 | Response factor standard; no oxygenate(s) added; 6 X 1 mL | SD-007 |
| ASTM D7096 | Reference Gasoline (contains no oxygenated compounds); 6 X 1 mL | SD-008-200 |
| ASTM D7169, D6352 | Reference oil 5010 for high temp simulated distillation; 5 mL | SD-020-02 |
| ASTM D7169, D6352 | Reference oil 5010 for high temp simulated distillation; 25 mL | SD-020-01C |
| ASTM D7169, D6352 | Retention time standard for high temp simulated distillation; 0.005% – 0.04% C5 – C100 with C12 and C40 markers in carbon disulfide; 6 X 1 mL | SD-SS3E-05 |
| ASTM D7169, D6352 | Retention time standard for high temp simulated distillation; 0.005% – 0.04% C5 – C100 with C12 and C40 markers;; dry/powder form; no carbon disulfide; must be reconstituted in carbon disulfide using provided instructions; ~7 mL when prepreared | SD-SS3E-05-NS |
| ASTM D7169, D6352 | Response factor standard for high temp simulated distillation; C10 – C50; 6 X 1 mL | SD-SS3E-05Q |
| D7213 | Retention time standard; 0.02 – 0.1% C5-C72 with C12 and C40 markers; Polywax 500; 6 X 1 mL | SD-SS3E-03 |
| Inlet Liners | ||
| ASTM D2887, D5307, D6352,D7169, D7500 | Glass inlet liners for SimDis®Inlet; 5/PK | SS-035-00 |
| ASTM D2887, D5307, D6352,D7169, D7500 | Glass liners for SimDis® Inlet for ‘fast’ simulated distillation method; 5/PK | SS-035-00.1 |
| ASTM D2887, D5307, D6352,D7169, D7500 | Glass inlet liners for Agilent Split/Splitless capillary inlet; DHA; 5/PK | SS-035-05 |
| Column Hardware and Ferrules | ||
| ASTM D7169, D6352, D7213 | Ferrules for high temperature simulated distillation methods; 1/16″ graphite | SS-030-14 |
| ASTM D2887, D5307, D6352, D7169, D7500 | Ferrules for SSI SimDis® Inlet (only);10/PK | SS-030-20 |
| ASTM D6352, D7169, D7500 | Ferrules for use with FID for high temperature simulated distillation – Detector side only; 10pk | SS-030-20D |
| ASTM D5134, D6729, D6730, D6733, D7096, D7900 | Ferrules for capillary split/splitless inlet; (Note: these ferrules are different from the ones used for the detector side of the analytical column. Refer to SD-030-35D below.);10/PK | SS-030-35 |
| ASTM D5134, D6729, D6730, D6733, D7096, D7900 | Ferrules for DHA/PIANO methods; DETECTOR SIDE ONLY; 10/PK | SS-030-35D |
| All | Nut for split/splitless capillary inlet | SS-032-00 |
| Inlet Septa | ||
| ASTM D2887, D5307, D6352, D7169 | Septa for use with SimDis® Inlet; 25/PK | SS-031-02 |
| ASTM D5134, D6729, D6730, D6733, D7900 | Septa for use with S/S inlet conducting for simulated distillation and PIANO analysis; 25/PK | SS-031-50 |
| Gas Filters / Traps | ||
| All | Hydrocarbon trap for carrier gas; 100cc with 1/8″ fittings | SS-350-001-100 |
| All | Hydrocarbon trap for carrier gas; 200cc with 1/8″ fittings | SS-350-001-100A |
| All | Oxygen indicating moisture trap; 50cc | SS-350-005C |
| Sulfur Analysis Methods | Sulfur Trap – ‘Large’ cartridge (22.5″ X 1.5″) with 1/8″ fittings | SS-350-008 |
| Glass Vials, Caps | ||
| All | Clear glass vials; 1.5ML; wide mouth | SD-014-01 |
| All | Glass sample vials; (12ml) case of 200 | SD-014-04 |
| All | Vial caps for glass sample vials (reference SD-014-04); 100 per package | SD-014-05 |
| All | Seals – Teflon/Silicon | SD-014B |
| All | Glass sample vials for use in automatic liquid sample; 2 mL volume 100 per package | SD-015 |
| ASTM D7169, D6352, D7213 | Glass scintillation style vials for high temperature simulated distillation | SD-2000-020 |
| Miscellaneous | ||
| ASTM D7169, D6352, D7213 | FID flame jet tip for use with wide bore columns conducting high temp simulated distillation methods (A standard flame tip will quickly clog up due to column bleed. This will, in turn, lead to inconsistent results.) | SD-011-01 |
